View 8x
The INNO View 8X is a premium core alignment fusion splicer designed for high-performance professional fibre installation and maintenance. With splicing from 4 seconds, heating from 9 seconds, built-in IoT and GPS, intelligent View Pro Manager connectivity and up to 350 splice-and-heat cycles, it combines precision, speed and advanced fleet management in one field-ready platform.
£2,950.00 +VAT
Included with every INNO splicer, backed by our UK service centre.
Quick enquiry
Ask about price, availability, trade-in or a demonstration. We’ll know which product you’re looking at, so just tell us what you need.
Key features
- 4 s
Ultrafast core-alignment splicing
Core alignment in around 4 seconds, with typical loss of 0.01 dB on single-mode fibre.
- 9 s
Rapid heating
The heater shrinks a 60 mm slim sleeve in as little as 9 seconds, with fast, even heat.
- 350
Cycles on one charge
The 7,000 mAh battery gives up to 350 splice-and-heat cycles. Use and charge at the same time over USB-C.
- GPS
Built-in GPS and wireless
Remote tracking, management and support through View Pro Manager.
- 6,000
Arcs per electrode set
Electrodes optimised for splice quality last up to 6,000 arcs.
- 5.0″
Large touchscreen
A clear, intuitive interface with control buttons, bright work lighting and a durable metal windproof cover.
Overview
The INNO View 8X is a premium single-fibre fusion splicer developed for technicians and contractors who require fast operation, precise core alignment and advanced connectivity for professional fibre network projects.
Using core alignment technology, the View 8X accurately aligns the fibre cores before fusion, helping achieve consistently low splice loss across different fibre types. INNO specifies typical loss as low as 0.01 dB for single-mode fibre.
Fast splicing for high-productivity projects
The View 8X is designed to reduce the time required for each splice cycle.
Splicing time: from 4 seconds
Heating time: from 9 seconds
INNO’s Pressure Heater Technology reduces sleeve heating time, while improved energy efficiency allows the View 8X to complete up to 350 splice-and-heat cycles on a single charge under the manufacturer’s stated conditions.
This makes it particularly suitable for contractors working on larger FTTH roll-outs, network deployments and projects where productivity and splice quality both matter.
INNO Instrument Exclusive Business Partner for the UK and Ireland
Why buy from Uptero
One team supports you from the first conversation to the last service, with everything your equipment needs in one place.
Expert sales advice
Help choosing the right equipment for your work and budget.
Manufacturer warranty
INNO warranty cover, handled here in the UK.
Service and repair
Calibration, servicing and repairs at our UK service centre.
Rental equipment
Splicers to hire for projects, busy periods and backup.
Accessories and spares
Genuine INNO parts, consumables and accessories in UK stock.
Technical support
Engineers on hand for faults, software updates and everyday questions.
View Pro Manager compatible
Manage every splicer from one dashboard
This splicer connects to View Pro Manager, INNO’s cloud platform for fusion splicer fleets. Follow results as they happen, keep complete records for audits and keep every splicer set up the way you want it.
- Live and historical splice results, with images and estimated loss
- GPS location of each splicer and job site
- Locked, pre-approved settings for every technician
- PDF reports and preventive maintenance alerts
Specifications
Technical specifications
| Model | View 8X |
|---|---|
| Alignment method | Core alignment |
| Number of fibres | Single |
| Applicable fibres | SM (G.652 & G.657) / MM (G.651) / DS (G.653) / NZDS (G.655) |
| Coating diameter | 100 µm – 3 mm |
| Cladding diameter | 80–150 µm |
| Cleave length | 5–16 mm |
| Typical splice loss | SM 0.01 dB / MM 0.01 dB / DS 0.03 dB / NZDS 0.03 dB / G.657 0.01 dB |
| Return loss | > 60 dB |
| Splice time |
|
| Splice programmes | Max. 300 modes |
| Electrode lifespan | 6,000 arc discharges |
| Heating programmes | Max. 100 modes |
|---|---|
| Heating time |
|
| Protection sleeve | 20–60 mm |
| Data output | USB-C, View Pro Manager (IoT & GPS) |
| Splice memory | 20,000 splice records / 20,000 images |
| Battery |
|
| Power supply | 12 V USB-C |
| Monitor | 5.0" colour LCD, full touchscreen |
| Magnification | ×360, ×520 |
| Size (H × W × D) | 145 × 160 × 131 mm (with rubber bumper) |
| Weight | 2.0 kg (including battery) |
| Pull test | 1.96–2.25 N |
Package & accessories
| In the box | Model |
|---|---|
| Cleaver | V2+ |
| SOC holder | FH-SOC-R |
| SOC heater cover | HTS-SOC-07 |
| Cooling tray | CG-26 |
| Electrodes | E-70 |
| Battery pack | LBT-7000C |
| USB adapter | USB-8P |
| USB charging cable | USB-11P |
| Thermal stripper | TS-X |
| Carrying case | ICC-61 |
| Shoulder strap | ST-02 |
| Optional accessories | Model |
|---|---|
| Alcohol pump | TK02-AP01 |
| Stripper | TK-MP01 |
| Cigarette lighter cable (USB-C) | CJ-13 |
| Heat-shrink sleeve (60 mm) | PS-60S |
| Magnetic detachable holder | FH-200/250S-1, FH-900S-1 |
Environmental conditions & tests
| Operating conditions |
|
|---|---|
| Storage conditions |
|
| Resistance tests |
|
Downloads & support
Software for this product, plus direct access to our UK technical team.
Software updates
- DownloadSoftware 1.08For units on V1.xx
New Touchscreen Support
General improvements
How to update
If the currently installed software is V1.00–V1.02, extract the package, copy all extracted files to the USB root and run the software upgrade twice. From V1.03 onward, you may use update.zip directly (or the extracted files), but the software upgrade must still be run twice.
After updating: Run the upgrade a second time (upgrade twice).
Need a different version? Contact us or WhatsApp
Every INNO splicer from Uptero carries a 3-year warranty. If it ever needs attention, our UK service centre turns repairs around in about 3 working days.
Ask our technical team
Questions about a fault, a software update or using this product? Send us the details and our UK engineers will get back to you.
